| Manufacturer | Garmin |
|---|---|
| Dimensions | 11.9 x 12.4 x 6.1 cm |
| Display size | 5.0 x 8.4 cm |
| Display resolution | 64 x 128 pixels |
| Display type | Black and white FSTN |
| Weight | 439 g |
| Waterproof | Yes |
| CANet | No |
| Sound alarm | Yes |
| Dual frequency sonar | No |
| Dual beam sonar | Yes |
| Zoom with split screen | No |
| Ultrascroll™ | Yes |
| See-thru® | Yes |
| Fish Symbol ID | Yes |
| AutoGain | Yes |
| Whiteline | Yes |
| Adjustable depth line | No |
| A-scope | No |
| Bottom lock | No |
| Water temperature journal | No |
| Water temperature sensor | Yes |
| Boat speed against water | No |
| Frequency | 80/200 kHz |
| Output power | 100 W (RMS), 800 W |
| Voltage range | 10-18 VDC |
| Max depth | 182 m |
| Cone angle | 45° or 15° |
